Slot Hood Design
ATMOS360’S Close Capture dust hoods with pneumatic cylinder actuated stripping baffles demonstrate superior performance in papermaking and converting applications. In area where close capture hoods are not feasible (an unsupported web or spatial constraints) we utilize general Area exhaust hoods. This combination of close capture and area hoods are used successfully on weak sheets such as facial and tissue lines. They provide optimum dust collection performance that result in improved process reliability.
PVC Fume Hoods
Hood design just doesn’t get much simpler than this approach. Raw edge hoods, while very simple to produce, provide the poorest performance in collecting contaminants at the point of generation. This hood configuration pulls air not only from in front of the duct opening, but, unfortunately, also from behind the hood opening, which makes it. Feb 25, 2011 Practical Slot Hood Design for Acid Mist Control of a Battery Charging Operation Marie L. Fitzgerald Douglas Battery Manufacturing Company, 500 Battery Drive, Winston-Salem, North Carolina, 27117, USA & Jonathan F. Hale Jackson-Hale Environmental Technologies (JHET) Inc., P.O. Box 1839, Clemmons, North Carolina, 27012, USA.
Fume Hoods serve a wide variety of industrial processes where toxic contaminants are present. They serve to capture fumes and route them into a ducting system where they can be removed from human and environmental contact.
Features:
- '68-'69 Camaro S/S Hood Item No. CRC-099: $7.50: 14. Mini Rectangle Pro Stock Hood Scoop Item No. CRC-102: $5.50: 15. Aero IV Pro Stock Hood Scoop Item No. CRC-103: $6.00: 16. Stock Vega Hood Item No. CRC-104: $7.00: 17. Short Old Style Pro Hood Scoop Item No. CRC-106: $5.50: 18. Cowl Induction Hood Scoop Item No. CRC-107: $5.00: 19.
- Hood “losses” Minimum duct design velocities. Slotted hoods Slots are used for proper distribution of air across a large area of contamination dispersion.
| All KCH fume hoods are designed in accordance with American Conference of Governmental Industrial Hygienists (ACGIH) standards. | |
| Fume hoods are chemical resistant and do not degrade as a result of the gases, vapors, or particulates the hoods capture. | |
| KCH custom-builds fume hoods in a wide assortment of configurations whether canopy style, side lateral, downdraft, or upright. | |
| KCH designs and builds exhaust hoods from the following materials: | |
| Type I or Type II, Grade 1 Gray PVC | CPVC |
| Polypropylene | FRP |
| Dual Laminate | Solid Fiberglass |
How they work:
All KCH hoods are designed to induce maximum airflow from the working environment that captures noxious vapor into a ventilation system as efficiently as possible.
KCH manufactures both enclosing hoods and exterior hoods. Enclosing hoods partially or totally enclose the contaminant at its source. Enclosing hoods, such as canopy hoods or laboratory enclosures, are especially necessary for emissions that involve hot air or large particulates that are being emitted vertically at high velocities. Exterior hoods operate beside a fume emission source but do not enclose it. The exterior hood collects contaminated air through induced flow from an exhaust fan, or combined with a jet of air that pushes the contaminant into the hood.
Hood Types
Hood Type: BUApplication: Updraft profile style hood typically 36' tall, mounted on the back of a tank and used when fuming is not excessive. Can be combined with push air system. |
Hood Type: BSLApplication: Low Profile single hood exhausting on one side of tank with the outlet on the end. Hood Type: BSL-D (not depicted)Application: Low Profile single hood exhausting between 2 tanks with 2 inlet slots and 1 outlet on the end. |
Hood Type: BB or BDApplication: Updraft profile style hood typically 12' tall and used when fuming is not excessive. |
Hood Type: B2L-B2LD-B4LApplication: Low profile, single or double hood with common plenum typically on 2 or 3 sides. Typically used when overhead clearance is a problem. |
Hood Specifications
Slot Hood Exhaust Design
Hood lengths can vary from as little as 12 inches to over 100 feet long. The basic hood shape is fabricated of 0.1875' (3/16) thick PVC and hot welded. For additional strength and reliability, joints are welded both inside and outside wherever possible, and corners along the length of the hood are heat formed.
Kitchen Hood Design
Slot Hood Design
Slot Hood Design Images
Slot dividers on vertical type hoods are internally reinforced using 0.25' (1.4) thick PVC sheet, angle spaced not greater than 12' and all lip type hoods have top and bottom slot section reinforced with 0.25' (1/4) PVC. To prevent warping, additional internal reinforcing is used as required to strengthen the hood at critical points
